Light 5X 40V Vertical 5-Axis Laser Machining Center

Light 5X 40V Vertical 5-Axis Laser Machining Center revolutionizes PCD/PCBN/CVD tool finishing with 0.003mm accuracy. It delivers 200% faster processing than EDM, with 50% lower costs. This innovative system combines NUM CNC controls and GTR software for seamless one-clamping machining, ideal for automotive and 3C electronics industries.

Welcome to OPMT Laser

Light 5X 40V Vertical 5-Axis Laser Machining Center

Light 5X 40V Vertical 5-Axis Laser Machining Center revolutionizes PCD/PCBN/CVD tool finishing with 0.003mm accuracy. It delivers 200% faster processing than EDM, with 50% lower costs. This innovative system combines NUM CNC controls and GTR software for seamless one-clamping machining, ideal for automotive and 3C electronics industries.

Master of Precision Finishing

Experience laser finishing of PCD/PCBN/CVD tools with an astonishing accuracy of 0.003mm, tolerance stabilized in ≤ 0.001mm.

Efficiency Expert

Enjoy up to 200% faster processing speeds compared to EDM, coupled with 50% lower costs per unit,Laser finishing of PCD tools with up to 3.0 mm/min.

CNC Tool machining Specialist

Leveraging the power and user-friendliness of NUM CNC controls and GTR cutting tool software, 3C tools can complete all machining in one clamping, enabling a seamless transition from EDM to laser machining.

Sample Applications

Features

High-precision machining for workpieces with large-curvature surfaces and complex contours

Widely used in for machining of PCD, CBN, ceramics, metal and other materials, and ability to  machine complex contours and profiles of welded-edge milling cutter, micro-edge tool, and thin-walled metal parts, etc.

Ultra-precise Workpiece Visualizatio

High-magnification CCD camera: real-time spatial positioning for high accuracy, enhanced quality control through high resolution imaging.

Intelligent Spatial Positioning for Optimal Processing

State-of-the-art infrared measuring probe: high-precision workpiece measurement in three dimensions.

Motors

The linear axes driven by linear motors, the rotary axes driven by torque motors.

High Positioning Accuracy and Fast Dynamic Response

The linear axes adopt rolling linear guide rails and cross roller bearing, low friction coefficient and fast response speed,full closed-loop grating scale is used for detection.

Long-term Stability

Natural marble base with good rigidity, high precision and strong reliability.

Specifications

Travel Unit Light 5X 40V
X-axis mm 400
Y-axis mm 250
Z-axis mm 300
Workbench
Dimensions of the horizontal workbench mm 500 X 500
Load capacity of the horizontal workbench kg 100
Dimensions of the C-axis workbench mm φ110
B-axis swing angle ° ±120°
Max. load capacity of the C-axis workbench kg 10
Accuracy
X/Y/Z-axis positioning accuracy mm 0.005
X/Y/Z-axis repeat positioning accuracy mm 0.003
B/C-axis positioning accuracy 10
B/C-axis repeat positioning accuracy 5
Machining range
Max. tool diameter mm φ100(φ200 in some models)
Max. tool length mm 200
Max. tool weight kg 8
Clamping interface of workpiece mm HSK-A63  manual  clamping
Machine dimensions
Floor space (L x W x H) mm 2700 x 1900 x 2600
Weight kg 3500
